Other Specifications are as above but Dual Chamber & Heating & Cooling system separate in both chambers.

Body and Inner parts are made of either copper or brass.

0.5 H.P. single phase, Chrome plated Brass & Mild Steel, Centrifugal Action, Motor Driven..

For  Counting of  seeds  up  to  9999  on digital  display. Suitable  for  Paddy,  Ragi  Maize, Pulses. Mustard, Cholam, Cumb, Cowpea, Horse gram and many other.

General Features: Micro  Controller  based,  LCD  display,  Membrane  Keyboard,  Easily detachable  pan, Electromagnetic Vibratory feeder, Counting speed can be regulated, Lot size programming, Programmable batch, number of lots in a batch through  membrane  keypad, electronic  sensor, Interface  capabilities  for  attaching  computer  and  printer,  Parallel  port  for Parallel  printer. Programmable soft start and stop, Programmable stop.
Technical: Counts seeds of sizes from 1 mm to 15 mm. Counts maximum up to 999999 seeds in a lot.  Power supply 220V / 50 Hz operated.

1 no. Dispensing Balance.1 no. Hand Magnifier - (4"dia) size, 1 set of Parikh – (9", 12", 14") size, Scoop Set, 1 no. Enameled plate – (12"dia) size, 1 no. Palm Husker, Measuring cylinders – (10cc, 50cc, 100cc), 1 no. Forceps, 1 no. Brass Seed Calliper, 1 no. Petri dish.

Capacity 1 Kg to 20 Kg a compact unit built on metal platform, with geared motor which revolves a drum. The drum rotates or brackets. Complete with set of balls mains lead and plug. With S.Steel Drum.

Analog measuring device for measurement of Length and Breadth of Seeds. The Dial used is ISI Marked.

Maintenance free,  Lower Power Consumption, Sample and trouble free mechanism.

 Painted Mild Steel or Stainless Steel, Dividing or Halving Dry Material.

 With ¼ H.P. motor reduction gear to carry up to six, 6” Or 8” Test sieves with one set of lid & pan . There is an upward and downward movement but is inclined from the vertical axis and the direction or inclination charges progressively in clock wise direction having frequency of about 270 vibration per minutes (without sieves & lid & pan).

For carry out wet sieves analysis material. Consist of a water reservoir and a holder for sieves which can be take up to 7 sieves of 8” dia with ¼  HP motor Electric operated.

GI Frame -12” Dia any size..
GI Frame -18” Dia any size.

Made of Brass or  G.I. and wire mesh or perforated M.S. sheet, designed to confirm to specification set by B.I.S. Standard sieves has 8" or 12" dia, 2 approx depth. Frames are skirted to nest together. Suitable for grain/seed grading.

Range 8.0% - 40%, Principle Resistance Measurement, Accuracy ±0.2%, Display Three Seven Segment Displays, Weight 9.5 Kg Approx. without accessories, Size 30x17x26 cms approx.

Range 8.0% - 40%, Principle Resistance Measurement, Accuracy ±0.2%, Display Three Seven Segment FND, Weight 22.5 Kg Approx. without accessories, Size 45x25x33cms approx., Power - Six 9V Dry Cells or 230 volts, 50 Hz AC through adaptor, Temperature Automatic.

For preparation of samples for analysis with minimum loss of moisture or volatile constituents. Unit having two stationery steel blade and rotary with steel edges provided in cast iron chambers. Willey mill is fitted on substantial cast iron base. Fitted with suitable motor supplied with S. Steel Hopper with Cover, three delivery sieves, having tops of 20, 40 and 80 mesh.

For wheat / rice, Regulator for variable blower speed with flow dial, Adjustment for air flow, On & off mode for fan, Pan to keep sample, Transparent cup to collect inert matter, Mode of collection centrifugal mains operated 70w appx. 220 v 50c/s.,

For determination of moisture content, measure moisture percentage by weight & drying simultaneously. Infra Red radiation are reflected by a bulb and its temperature is controlled by a regulator.

Made of  Heavy thick CRC Sheet duly powder coated. Size of  tray is 12”x12”x4” (Height) and  into four compartment with index card holder, lock and key.
